Passenger Management Device (HSM-CTD45H / HSM-CTD58H)
Passenger Management Device (HSM-CTD45H / HSM-CTD58H)
Product Specifications
| Model Name | HSM-CTD45H | HSM-CTD58H | |
|---|---|---|---|
| Power(kW/PS) | (33.5/45) | (43/58) | |
| Dimensions | Length x Width x Height(mm) | 3,610 x 1,940 x 2,700 | 3,780 x 2,060 x 2,730 |
| Weight(kg) | 2,370 | 2,522 | |
| Minimum ground clearance(mm) | 650 | 635 | |
| Engine | Engine model | 3HT5(3420-2655) | 3HT5(4318-2655) |
| Engine type | Vertical water-cooled 3-cylinder 4-stroke diesel engine | ||
| Displacement(CC) | 1,826 | ||
| Governor type | Electronic control type | ||
| Main clutch type | Dry disc type | ||
| Drive Unit | Transmission type | Main: Mechanical (synchronous mesh) Sub: Mechanical (constant mesh) |
|
| Gear stages | Main: 4 forward/4 reverse Sub: 2 stages (low, high) + Ultra-low speed: 2 stages (on, off) |
||
| Steering type | Full hydraulic (steering wheel type) | ||
| PTO | Type (diameter(mm)) | Independent type (35) | |
| Speed (r/min) | 3 stages (540, 750, 1000) | ||
| Implement mounting device | Type | Fixed hitch type | |
| Connection type | 3-point hitch | ||
| Possible work | Rotary, seeder, ridger, etc. | ||
| Implement lifting device | Type | Hydraulic type | |
| Hydraulic pump type | Gear type | ||
※ Specifications are subject to change without notice for performance improvement
Product Features
01
Control 4
- Horizontal control
- Automatic draft/depth control function
- AUTO PTO
- One-touch/turn-up/back-up function
02
Automated function 'Take 5'
- PTO cruise function
- HMS function
- Escort function
- Torque compensation
- Momentary RPM down function during turns (applied to PSC models)
