Boom Sprayer
Boom Sprayer(HSMS-14)
Product Specifications
| Model Name | HSMS-14 | |
|---|---|---|
| Dimensions (mm) |
Boom Length | 13,500 |
| Boom Height from Ground (Minimum) | 450 | |
| Boom Height from Ground (Maximum) | 1,370 | |
| Sprayer Size(A) | 100A | |
| Tank Capacity(L) | 500 | |
※ Specifications may be subject to change without notice for performance improvements.
Product Features
01
The spray tank is made from
lightweight, highly abrasion-resistant
FRP material. The attachment method
uses a 3-point linkage, making it easy
to attach and detach from rider
mowers and tractors.
02
The rider mower boom sprayer can
be directly connected via a one-touch
system, allowing simultaneous pesticide
spraying on five ridges.
03
The two-stage foldable boom arms
are designed for easy operation from
the driver’s seat.
04
The central foldable spray lever
allows easy control of each boom arm
from the driver’s seat.
05
The use of aluminum profiles
prevents boom arm twisting and
realizes an ultra-lightweight boom arm. The boom is designed to maximize
spraying coverage with a 12-meter
spraying range
06
Designed for easy attachment and
detachment.
07
A tilting device is built in to adjust
the height of the left and right boom
arms according to the conditions of
the cultivation field.
