Multi-Supplier Contract Amount: 50,800,000KRW
| Model | HSM-CT58 | |
|---|---|---|
| Power(PS) | 58 | |
| Dimensions | LengthxWidthxHeight(mm) | 3,800 x 1,920 x 2,590 |
| Weight(kg) | 1,988 | |
| Axle distance(mm) | 530 | |
| Minimum ground clearance(mm) | 450 | |
| Engine | engine output(kw/rpm) | 40/2,600 |
| displacement(CC) | 2,287 | |
| Fuel tank capacity(ℓ) | 45 | Drive Unit | Front wheel and rear wheel | F16 - R16 |
| front tire(inch) | 9.5-20 | |
| rear tire(inch) | 9.5-36 | |
| PTO | PTO number of revolutions | 584 / 790 / 1,088 |
※ Specifications are subject to change without notice for performance improvement
Operators can check the contents of the instrument panel at a glance.
You can shift the gears by pressing a button and using the gear lever without operating the clutch pedal.
The rear work mechanism can be finely adjusted via a lever.
Rear work tool can be fine-tuned via lever (including one-touch function)
The lever is located under the seat for convenient operation.
It is located on the right side of the driver's seat for easy operation.
Equipped with front and rear LED work lights, it provides a wide field of vision when working at night.
By applying the organ pedal, it is possible to maintain a constant RPM even when the body shakes.
Horizontal control and lower link adjustment are possible.
You can mount the work tool to fit the rear 6 ports.
It is convenient to operate in a dial format, has less dirt accumulation, and has a short turning radius.
